STRATOS X703
€
97
€
color
patented STRATOS X703® profile for stretch ceilings with a harpoon fastening system. designed for constructing structures, niches, and bypassing complex walls. features an led tape shelf.
brand: alumineu
color: no color
lenght: 2000 mm
material: aluminum
width of light flux: 29 mm
bending radius: >120 mm
membrane attachment: harpoon
brand: alumineu
color: no color
lenght: 2000 mm
material: aluminum
width of light flux: 29 mm
bending radius: >120 mm
membrane attachment: harpoon
STRATOS X703
€
97
€
color
patented STRATOS X703® profile for stretch ceilings with a harpoon fastening system. designed for constructing structures, niches, and bypassing complex walls. features an led tape shelf.
brand: alumineu
color: no color
lenght: 2000 mm
material: aluminum
width of light flux: 29 mm
bending radius: >120 mm
membrane attachment: harpoon
brand: alumineu
color: no color
lenght: 2000 mm
material: aluminum
width of light flux: 29 mm
bending radius: >120 mm
membrane attachment: harpoon
STRATOS X703
two-level profile
profile details
- groove for band.
- shelf for led-strip.
- vertical groove for harpoon.
- joining groove.
construction
accessories
joining rods: ∅3 mm, 2 pcs. per 1 joint.
Cut connecting band: 2 pcs. per 1 joint.
profile STRATOS X703
cad file
We have prepared files for designers with our profiles. Now interior visualization using aluminum products is even easier
cad file
installation guide
installation guide
installation
Fasten to the ceiling using self-tapping screws or anchors through mounting angle brackets; fixing spacing not exceeding 0.7 m on straight sections and 0.3 m on curved sections.
On curved sections, the profile cuts are sealed with metallized tape to eliminate gaps.
Curved sections can be in either horizontal or vertical planes.
On curved sections, the profile cuts are sealed with metallized tape to eliminate gaps.
Curved sections can be in either horizontal or vertical planes.
Without transitions or gaps. Using a Ø2 mm rod.
When using a profile with lighting, do not use colored membranes or matte-finish membranes.
the membrane with a standard cut is inserted using a spatula with a working edge at least 35 mm long and angled at 70–90°.
Can be mounted in 2 rows.
profile in interiors
STRATOS X703
for creating structures, niches, and bypassing complex walls. features an led tape shelf.
