patented INVISIA X209® spacer profile for stretch ceilings with a harpoon fastening system. designed to accommodate staircases and skylight.
brand: alumineu color: black matte, white matte lenght: 2000 mm material: aluminum shadow gap: 7,7mm membrane attachment: harpoon
INVISIA X209
shadow profile
profile details
Notches to increase adhesion when used with plaster or putty finishes.
angled groove for harpoon.
joining groove.
construction
accessories
joining rods: ∅2 mm, 1 pcs. per 1 joint.
Cut connecting band: 1 pcs. per 1 joint.
profile INVISIA X209
cad file
We have prepared files for designers with our profiles. Now interior visualization using aluminum products is even easier
cad file
installation guide
installation guide
installation
Fasten to the ceiling using self-tapping screws or anchors through mounting angle brackets, or fasten with self-tapping screws to the slope of a roof window. Fixing spacing: 500 mm.
Without transitions or gaps. Using a Ø2 mm rod and a 15 mm wide band.
The membrane with standard cut is inserted using a spatula with a working part at least 35 mm long and angled at 15–20°.
