patented INVISIA X206® ceiling spacer profile for stretch ceilings featuring a harpoon mounting system.
brand: alumineu color: black matte lenght: 2000 mm material: aluminum shadow gap: 7,7 mm membrane attachment: harpoon
INVISIA X206
shadow profile
profile details
Marking for self-tapping screws installation.
angled groove for harpoon.
joining groove.
construction
accessories
Joining rods: ∅2 mm, 1 pcs. per 1 joint.
profile INVISIA X206
cad file
We have prepared files for designers with our profiles. Now interior visualization using aluminum products is even easier
cad file
installation guide
installation guide
installation
Fasten to the ceiling using self-tapping screws or anchors through mounting angle brackets. Fixing spacing shall not exceed 300–350 mm.
without transitions or gap.Using a Ø2 mm rod.
The membrane with standard cut is inserted using a spatula with a working part at least 35 mm long and angled at 15–45°.
Insert the spatula between the harpoon and the profile locking lip, heat the harpoon, press on the membrane, and move the spatula along the profile; the membrane can be removed without damage and reused.
