patented CLASSIX X101® profile for stretch ceilings with a harpoon mounting system. designed for navigating complex walls. the profile perimeter is closed with a wall insert.
brand: alumineu color: no color lenght: 2000 mm material: aluminum membrane attachment: harpoon
patented CLASSIX X101® profile for stretch ceilings with a harpoon mounting system. designed for navigating complex walls. the profile perimeter is closed with a wall insert.
brand: alumineu color: no color lenght: 2000 mm material: aluminum membrane attachment: harpoon
CLASSIX X101
seamless profile
profile details
vertical groove for harpoon.
joining groove.
construction
accessories
profile CLASSIX X101
cad file
We have prepared files for designers with our profiles. Now interior visualization using aluminum products is even easier
go to cad file
installation guide
installation guide
installation
Fasten to the ceiling with self-tapping screws or anchors, either directly or through mounting angle brackets. Fixing spacing: 200–300 mm.
Without transitions or gaps. Using a Ø2 mm rod and a 15 mm wide band.
The membrane with standard cut is inserted using a spatula with a working part at least 35 mm long and angled at 15–20°.
without damage.
Go to catalog
View and download the Alumineu catalog
catalog
instagram
Subscribe and follow us on Instagram
Go to Instagram
profile in interiors
CLASSIX X101 in interior
the profile perimeter is closed with a wall insert.
