LIGHTRA X030
€
€
color
patented LIGHTRA X030® separation profile for stretch ceilings with a harpoon mounting system. designed for creating a light line.
brand: alumineu
color: no color
lenght: 2000 mm
material: aluminum
bending radius: >500 mm
width of light flux: 30 mm
membrane attachment: harpoon
brand: alumineu
color: no color
lenght: 2000 mm
material: aluminum
bending radius: >500 mm
width of light flux: 30 mm
membrane attachment: harpoon
LIGHTRA X030
€
€
color
patented LIGHTRA X030® separation profile for stretch ceilings with a harpoon mounting system. designed for creating a light line.
brand: alumineu
color: no color
lenght: 2000 mm
material: aluminum
bending radius: >120 mm
width of light flux: 14 mm
membrane attachment: harpoon
brand: alumineu
color: no color
lenght: 2000 mm
material: aluminum
bending radius: >120 mm
width of light flux: 14 mm
membrane attachment: harpoon
LIGHTRA X030
light profile
profile details
- groove for band.
- angled grooves for harpoon.
- joining grooves.
- marking for self-tapping screw installation.
- shelf for LED-strip.
construction
accessories
joining rods: ∅2 mm, 2 pcs. per 1 joint
Cut connecting band: 2 pcs. per 1 joint
profile LIGHTRA X030
Ready-made corners
Zamów pliki CAD
Wypełnij krótki formularz, a wyślemy ci potrzebne pliki CAD
Installation guide
Installation guide
installation
Fasten to the ceiling using self-tapping screws or anchors through the mounting angle brackets.
The fixing spacing on straight sections shall not exceed 1 m; on curved sections, not more than 0.7 m
On curved sections, an edge trim is used together with the profile.
The relief cuts in the profile shall be sealed with metallized adhesive tape to eliminate light gaps.
The fixing spacing on straight sections shall not exceed 1 m; on curved sections, not more than 0.7 m
On curved sections, an edge trim is used together with the profile.
The relief cuts in the profile shall be sealed with metallized adhesive tape to eliminate light gaps.
without step or gap.Using a ∅2 mm dowel
Standard-cut membrane is inserted using a straight standard spatula.
For freestanding lines, bond the membrane to the end element.
For freestanding lines, bond the membrane to the end element.
without damage.
Closed with a light-diffusing insert or diffuser in white or black color. Easy access for replacement, without removing the ceiling membrane.
Profile in interiors
LIGHTRA X015 in interior
designed for creating linear light lines
LIGHTRA X015 in interior
designed for creating linear light lines
