patented CURTINA X404® profile for creating concealed curtain niches with three tracks for installing curtains and sheers. designed for a harpoon fastening system with bottom membrane insertion.
brand: alumineu color: white gloss lenght: 2200 mm / 3200 mm material: aluminum number of tracks: 3 membrane attachments: harpoon
patented CURTINA X404® profile for creating concealed curtain niches with three tracks for installing curtains and sheers. designed for a harpoon fastening system with bottom membrane insertion.
brand: alumineu color: white gloss lenght: 2200 mm / 3200 mm material: aluminum number of tracks: 3 membrane attachment: harpoon
CURTINA X404
cornice profile
profile details
Reinforced bumper for rigidity.
Marking for self-tapping screws installation.
shelf for Led-strip.
groove for band.
angled groove for harpoon.
joining groove.
construction
accessories
Joining rods: ∅2 mm, 2 pcs. per 1 joint.
Cut connecting band: 2 pcs. per 1 joint.
profile CURTINA X404
cad file
We have prepared files for designers with our profiles. Now interior visualization using aluminum products is even easier
go to cad file
installation guide
installation guide
installation
Fasten to the ceiling using self-tapping screws or anchors through mounting angle brackets. Fixing spacing shall not exceed 1.5 m.
Without transitions or gaps. Using a Ø2 mm rod and a 15 mm wide band.
The upper-level membrane is inserted using a standard straight spatula, while the lower-level membrane is inserted using a spatula with a working part at least 35 mm long and angled at 70–90°.
without damage.
Maximum width 25 mm. Can be replaced without removing the membrane.
