patented CONTURA X601® wall-mounted contour profile for stretch ceilings with a harpoon fastening system. features an led tape shelf for downward lighting through the ceiling membrane. the profile perimeter is closed with a wall insert.
brand: alumineu color: no color lenght: 2000 mm material: aluminum width of light flux: 30 mm membrane attachment: harpoon
patented CONTURA X601® wall-mounted contour profile for stretch ceilings with a harpoon fastening system. features an led tape shelf for downward lighting through the ceiling membrane. the profile perimeter is closed with a wall insert.
brand: alumineu color: no color lenght: 2000 mm material: aluminum width of light flux: 30 mm membrane attachment: harpoon
CONTURA X601
contour profile
profile details
marking for wall mounting.
shelf for led-strip.
vertical groove for harpoon.
joining groove.
constuction
accessories
Joining rods: ∅2 mm, 2 pcs. per 1 joint.
profile CONTURA X601
cad file
We have prepared files for designers with our profiles. Now interior visualization using aluminum products is even easier
cad file
installation guide
installation guide
installation
Fastened to the wall with self-tapping screws or anchors; fixing spacing not exceeding 150 mm.On curved sections, a finishing lip is used together with the profile, and the profile relief cuts are sealed with metallized tape to eliminate light gaps.
Without transitions or gaps. Using a Ø2 mm rod.
Do not use with colored membranes or matte-finish membrane.
The membrane with a standard cut is inserted using a spatula with a working edge at least 35 mm long and an angle of 15–45°.
without damage.
