patented UNITEXA Z701® profile for creating ceiling niches and lighting fixtures in fabric stretch ceilings.
brand: alumineu color: black matte, white matte lenght: 2000 mm material: aluminum membrane attachment: clips, harpoon
UNITEXA Z701
two-level profile
profile details
joining groove.
angled groove for harpoon.
groove for band.
groove for clips.
construction
accessories
clip: 1 pc.
UNITEXA Z701 profile: 1 pc.
cad file
We have prepared files for designers with our profiles. Now interior visualization using aluminum products is even easier
go to cad file
Zamów pliki CAD
Wypełnij krótki formularz, a wyślemy ci potrzebne pliki CAD
installation guide
installation guide
installation
Fasten to the ceiling using self-tapping screws or anchors through mounting angle brackets; fixing spacing not exceeding 1 m on straight sections and 0.7 m on curved sections.
With connectors, without transitions or gaps.
The membrane is inserted using a spatula between the profile blade and the clips.
